This article discusses software internally used by Apple.

Acquiring a copy without Apple's consent is illegal and may result in being scammed.
Engaging in illegal activity is not condoned. This information is provided for educational purposes only.

HomeDiagnostic.pkg
Homediags 18B86.png
HomeDiagnostic.pkg (18B86)
Original author(s) Apple Inc.
Developer(s) Apple Inc.
Stable release 18B86
(latest known version)
Operating system macOS
Size 122-392 MB
Available in English
Type Package
License Closed source

HomeDiagnostic.pkg is a package which contains apps that are used by Foxconn and Apple. The package install apps (see Applications by Build, a crash dumper which launches when an iDevice is connected and dumps the devices logs to the computer, an Xcode Organizer panel and a handful of command line tools. Applications from this package are installed to /AppleInternal/Applications instead of /Applications and the command line tools are installed to /usr/local/bin. The only exception to this was AirSwitch which, prior to HomeDiagnostic.pkg build 18B86, was installed to /Applications.

It should be noted that the name of the actual package is HomeDiagnostic.pkg and not HomeDiagnostics.pkg

HomeDiagnostic.pkg

The following apps are included in most builds: PurpleRestore, PurpleSNIFF, PurpleFAT, SkankPhone, SkankTunes/FakeTunes, ScreenShotr, DCSD, PurpleBuildSanitizer, iOS Menu, iPhone Menu, PurpleConsole, PowerWarriorX, iRemoteX and CarDisplaySim.

Package Contents

Like a lot of packages, HomeDiagnostic.pkg is a package containing multiple smaller packages inside, along with other files such as a license.rtf. As of build 18B86 these packages include:

  • HomeDiagnostic.pkg: The package containing most applications and tools.
  • Astris_iOS.pkg: Likely installs Astris, for use with internal iDevice cables
  • AstrisAgent.pkg: Likely installs components related to Astris
  • CoreTypes.pkg: Unsure
  • MobileDevice.pkg: Unsure

Changelog

17A400

  • AirSwitch, a tool to install OTA updates from internal servers using a Kanzi Cable, is now included
  • PurpleRabbit, a tool for running tests and handling firmware/software on prototype iDevices, is now included

18B86

  • AtlasUI, the purpose of which is currently unknown, is now included
  • AtlasRecordsUI, the purpose of which is currently unknown, is now included
  • AirSwitch is now installed to /AppleInternal/Applications instead of /Applications

Applications by Build

(Work in progress) Fields missing a value (will just have --) need to be filled in. Most of these are because the app won't stay open long enough to see more version info or no other version number is provided by the app.

Frisco 13F40
Application Version
DCSD 1.0
iOS Menu 1
iPhone Menu 1.0
PowerWarriorX 383
PurpleBuildSanitizer 1.0
PurpleConsole 1.0
PurpleFAT 58.2.13
PurplePod 1
PurpleRestore 3 3.0
PurpleSNIFF 2.0
ScreenShotr 174
SkankPhoto 174
SkankTunes 5.0
stack 1.0
PurpleRegister 2.0.0
Whitetail 14A171
Application Version
CarDisplaySim 1.0
DCSD 1.0
iOS Menu 1
iPhone Menu 1.0
PowerWarriorX 382
PurpleBuildSanitizer 1.0
PurpleConsole 1.0
PurpleFAT 59.2.13
PurplePod 1
PurpleRestore 3 3.0
PurpleSNIFF 2.0
ScreenShotr 174
SkankPhoto 174
SkankTunes 5.0
stack 1.0
PurpleRegister 2.0.0
Butler 14B70
Application Version
CarDisplaySim 1.0
DCSD 1.0
iOS Menu 1
iPhone Menu 1.0
PowerWarriorX 391
PurpleBuildSanitizer 1.0
PurpleConsole 1.0
PurpleFAT 59.2.13
PurplePod 1
PurpleRestore 3 3.0
PurpleSNIFF 2.0
ScreenShotr 174
SkankPhoto 174
SkankTunes 5.0
stack 1.0
PurpleRegister 2.0.0
Tigris 15A278b
Application Version
CarDisplaySim 1.0
DCSD 1.0
iOS Menu 1
iPhone Menu 1.0
PowerWarriorX 399
PurpleBuildSanitizer 1.0
PurpleFAT 59.2.14
PurplePod 1
PurpleRestore 3 3.0
PurpleSNIFF 2.0
ScreenShotr 174
SkankTunes 5.0
stack 1.0
Yukon 17A400
Application Version
AirSwitch 0.80
CarDisplaySim 1.0
DCSD 1.0
FakeTunes 5.0
iOS Menu 1
iPhone Menu 1.0
iRemoteX 1
PowerWarriorX 436
PurpleBuildSanitizer 1.0
PurpleFAT 59.2.14
PurpleRabbit 2.1
PurpleRestore 3 3.0
PurpleSNIFF 2.0
ScreenShotr 174
stack 1.0
AzulB 18B86
Application Version Build
AirSwitch 1.012 18B86
AtlasRecordsUI 2.30.12 --
AtlasUI 2.30.12 --
CarDisplaySim 1.0 --
DCSD 1.0 --
FakeTunes 5.0 932
iOS Menu 1.0 --
iPhone Menu -- 1
iRemoteX 1.0 1
PowerWarriorX 504 504
PurpleBuildSanitizer 1.0 8.10.0
PurpleFAT 59.2.14 --
PurpleRabbit 61.40.4 301
PurpleRestore 3 3.0 580.40.19
PurpleSNIFF 2.0 83
ScreenShotr -- 174
stack 1.0 73.1
