iPhone 3GS

This is the iPhone 3GS. It was released on 19 June 2009 with a price tag of $199 for the 16GB model and $299 for the 32GB model, in the U.S., Canada and major European countries. Prices vary depending on the mobile operator. It features the same exterior design as the iPhone 3G, but has new internal features such as video recording, voice control, digital compass, faster CPU, increased RAM, Nike+ support, etc. The name used in firmware is iPhone2,1.

GPS

The iPhone 3GS uses the Infineon Hammerhead II PMB2525, like the iPhone 3G.

Baseband

The iPhone 3GS uses the X-Gold 608 baseband chip, same as in the iPhone 3G.

Application Processor

It makes use of the S5L8920 application processor.

Known Exploits

Bootrom

iBoot

Bluetooth & Wi-Fi Chip

The 3GS uses the Broadcom BCM4325 single-chip Bluetooth/FM/WLAN device.

Compass

The 3GS comes with a digital compass. By rumors this is the Asahi Kasei – AK8973 Chip.

Specifications

  • Size: 4.5 inches (115.5 mm) (height) × 2.4 inches (62.1 mm) (width) × 0.48 inches (12.3 mm) (depth)
  • Color: Black or White
  • Battery: Up to 12 hours of 2G talk, 5 hours of 3G talk, 5 (3G) or 9 (Wi-Fi) hours of Internet use, 10 hours of video playback, and up to 30 hours of audio playback, lasting over 300 hours on standby
  • Weight: 135 g (4.8 oz)
  • 3G: Broadband data speeds, supporting 7.2Mbps HSDPA
  • Rear camera: 3.15 MP with Autofocus and manual focus (Tap to focus), supporting VGA video recording at 30 FPS
  • Connector: 30-pin

More specifications available in GSMArena.
